Quick Answer
This gray rubber wheel with PA hub has a 160 mm outer diameter and a 45 mm width. The supplied drawing includes multiple hub reference diameters for installation review. Custom wheel dimensions, rubber compound, Shore A hardness, color and hub geometry can be evaluated according to your application requirements.
Product Overview
The gray rubber wheel with PA hub combines a light gray rubber tread with a rigid PA hub for industrial wheel applications. The supplied product marking is 160/45-126.5, which indicates a 160 mm outer diameter and a 45 mm wheel width. The sectional drawing shows several hub reference diameters, including Ø73.1 mm, Ø65.1 mm, Ø55.9 mm, Ø53.3 mm, Ø47 mm and Ø35 mm, together with axial reference dimensions of 5.8 mm, 4.9 mm and 13.7 mm. This wheel is suitable for equipment that requires a rubber running surface with a molded PA hub structure. Buyers should confirm the required bore size, installation method, operating load, running speed and application environment before ordering.
Key Features
- Specified wheel size: 160 mm outer diameter × 45 mm width.
- Product reference shown in the supplied image: 160/45-126.5.
- Light gray rubber tread with a PA hub.
- Hub drawing includes multiple reference diameters for installation review.
- Reference diameters shown include Ø73.1 mm, Ø65.1 mm, Ø55.9 mm, Ø53.3 mm, Ø47 mm and Ø35 mm.
- Rubber tread provides a compliant running surface for industrial wheel assemblies.
- PA hub provides a rigid internal support structure.
- Rubber compound, Shore A hardness and dimensional tolerance are available upon request.
Size / Dimensions
| Dimension Item | Specification |
|---|---|
| Product Reference | 160/45-126.5 |
| Outer Diameter (OD) | 160 mm |
| Width | 45 mm |
| Hub Reference Diameter A | Ø73.1 mm |
| Hub Reference Diameter B | Ø65.1 mm |
| Hub Reference Diameter C | Ø55.9 mm |
| Hub Reference Diameter D | Ø53.3 mm |
| Hub Reference Diameter E | Ø47 mm (+0.05 / -0.10 mm) |
| Hub Reference Diameter F | Ø35 mm |
| Axial Reference Dimension A | 5.8 mm |
| Axial Reference Dimension B | 4.9 mm |
| Axial Reference Dimension C | 13.7 mm |
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Gray Rubber Wheel with PA Hub |
| Material | Rubber tread with PA hub |
| Hardness | Available upon request |
| Color | Gray |
| Manufacturing Process | Available upon request |
| Application | Industrial wheel assemblies |
| Customization | Wheel size, hub dimensions, rubber compound, Shore A hardness, color, dimensional tolerance and packaging can be reviewed according to the application requirements. |
| MOQ | Contact us for details |
| Tooling | Tooling cost depends on the drawing and product structure |
| Sample Availability | Available upon request |
| Lead Time | Available upon request |
| Compliance Options | Available upon request |
Applications
This gray rubber wheel with PA hub can be evaluated for industrial wheel assemblies that require a rubber running surface and a molded hub structure. The wheel may be used in equipment where controlled rolling, low-impact contact and a stable hub interface are important. The 160 mm outer diameter and 45 mm width should be checked against the available installation space. Buyers should also confirm the mounting method, mating shaft or bore dimensions, operating load, running speed, duty cycle and exposure to water, dust, oil or cleaning chemicals. The final rubber compound and hardness should match the actual working conditions.
Customization Options
Custom gray rubber wheels with PA hub can be reviewed according to a 2D drawing, 3D model or physical sample. Buyers can specify the outer diameter, width, hub geometry, installation dimensions, rubber compound, Shore A hardness, color, dimensional tolerance and packaging method. Material selection depends on the application conditions. To support an efficient quotation, please provide the operating load, speed, floor or running surface, installation method, temperature range, contact media and estimated annual quantity. If special hub dimensions or assembly details are required, please include the complete drawing. Tooling cost depends on the drawing and product structure.
What Information Should Buyers Provide for a Quote?
- Product drawing or physical sample
- Dimensions and tolerances
- Rubber material
- Shore A hardness
- Operating temperature
- Contact media
- Application environment
- Required quantity
- Estimated annual volume
- Compliance requirements
- Packaging requirements
FAQ
Can the dimensions of this gray rubber wheel with PA hub be customized?
Yes. Custom dimensions can be reviewed based on your 2D drawing, 3D model or physical sample. Please provide the required outer diameter, width, hub dimensions, bore or shaft interface and dimensional tolerance so the wheel structure can be evaluated correctly.
How should buyers select the rubber material and hardness?
The rubber material and Shore A hardness should be selected according to the operating load, running speed, surface condition, temperature and contact media. Material selection depends on the application conditions. If these conditions are provided, the wheel structure can be reviewed more accurately.
Are samples available for this gray rubber wheel with PA hub?
Sample availability is available upon request. Please send your drawing, physical sample or detailed specification so the product structure, tooling status and sample arrangement can be reviewed before quotation.
Is tooling required for a custom PA hub wheel?
Tooling requirements depend on the wheel size, hub geometry, rubber profile and overall product structure. If the design matches existing tooling, this should be reviewed first. For a new design, tooling cost depends on the drawing and product structure.
How is the lead time confirmed?
The lead time is confirmed after reviewing the drawing, wheel dimensions, rubber compound, tooling status, order quantity and inspection requirements. Buyers should provide the expected quantity and delivery schedule when requesting a quotation.
Can the hub dimensions in the drawing be modified?
Yes. The hub dimensions can be reviewed according to the required installation structure. Please provide the mating part dimensions, shaft or bore details and tolerance requirements so the PA hub design can be matched to your assembly.
Request a Custom Quote
Send your 2D drawings, 3D models or physical samples for a technical review of your gray rubber wheel with PA hub. Please include dimensions, hub requirements, rubber material preference, Shore A hardness, operating conditions and estimated annual quantity so we can prepare a practical quotation.
